6502-FG
6502-FG sets a male NPTF pipe end 45 degrees from a female JIC 37° swivel end in a forged elbow, easing a pipe port into a flare line at a shallow angle.
- Shape
- Elbow, Swivel
- Side 1
- Male NPTF 30°
- Side 2
- Female JIC Swivel
- Standard
- SAE J476 / SAE J514 - Class 2B Thread
- Material
- Steel
- Plating
- Trivalent Zinc
- Part numbers
- 16 in this series
| Part Number | Side 1 | Side 2 | Thread | Material | Plating | Price | Stock | |
|---|---|---|---|---|---|---|---|---|
| 6502-02-02-FG | 1/8" Male NPTF 30° | 1/8" Female JIC Swivel | 5/16-24 UNF | Steel | Trivalent Zinc | $10.05 | In stock | View |
| 6502-03-03-FG | 3/16" Male NPTF 30° | 3/16" Female JIC Swivel | 3/8-24 UNF | Steel | Trivalent Zinc | $13.44 | In stock | View |
| 6502-04-04-FG | 1/4" Male NPTF 30° | 1/4" Female JIC Swivel | 7/16-20 UNF | Steel | Trivalent Zinc | $6.37 | In stock | View |
| 6502-05-05-FG | 5/16" Male NPTF 30° | 5/16" Female JIC Swivel | 1/2-20 UNF | Steel | Trivalent Zinc | $21.88 | In stock | View |
| 6502-06-06-FG | 3/8" Male NPTF 30° | 3/8" Female JIC Swivel | 9/16-18 UNF | Steel | Trivalent Zinc | $6.41 | In stock | View |
| 6502-08-08-FG | 1/2" Male NPTF 30° | 1/2" Female JIC Swivel | 3/4-16 UNF | Steel | Trivalent Zinc | $9.98 | In stock | View |
| 6502-10-08-FG | 5/8" Male NPTF 30° | 1/2" Female JIC Swivel | 7/8-14 UNF | Steel | Trivalent Zinc | $24.22 | In stock | View |
| 6502-10-10-FG | 5/8" Male NPTF 30° | 5/8" Female JIC Swivel | 7/8-14 UNF | Steel | Trivalent Zinc | $14.32 | In stock | View |
| 6502-12-12-FG | 3/4" Male NPTF 30° | 3/4" Female JIC Swivel | 1-1/16-12 UN | Steel | Trivalent Zinc | $16.35 | In stock | View |
| 6502-12-16-FG | 3/4" Male NPTF 30° | 1" Female JIC Swivel | 1-1/16-12 UN | Steel | Trivalent Zinc | $43.93 | In stock | View |
| 6502-14-14-FG | 7/8" Male NPTF 30° | 7/8" Female JIC Swivel | 1-3/16-12 UN | Steel | Trivalent Zinc | $89.29 | In stock | View |
| 6502-16-12-FG | 1" Male NPTF 30° | 3/4" Female JIC Swivel | 1-5/16-12 UN | Steel | Trivalent Zinc | $53.38 | In stock | View |
| 6502-16-16-FG | 1" Male NPTF 30° | 1" Female JIC Swivel | 1-5/16-12 UN | Steel | Trivalent Zinc | $30.38 | In stock | View |
| 6502-20-20-FG | 1-1/4" Male NPTF 30° | 1-1/4" Female JIC Swivel | 1-5/8-12 UN | Steel | Trivalent Zinc | $61.29 | In stock | View |
| 6502-24-24-FG | 1-1/2" Male NPTF 30° | 1-1/2" Female JIC Swivel | 1-7/8-12 UN | Steel | Trivalent Zinc | $93.80 | In stock | View |
| 6502-32-32-FG | 2" Male NPTF 30° | 2" Female JIC Swivel | 2-1/2-12 UN | Steel | Trivalent Zinc | $301.98 | In stock | View |
No parts on this page match the filter. or try the catalog search.
Full specifications for each part — connections, thread standards, configuration, and weight — are on the product page. To identify an unknown thread, see the thread identification guide and size charts.
