JIC 37° Flare Fittings · 2504-FG family
2504-08-08-FG
1/2" Male JIC x 1/2" Female NPTF 30° · Union Elbow
$8.63
per pieceIn stock
- Side 1
- 1/2" Male JIC
- Side 2
- 1/2" Female NPTF 30°
- Material
- Steel
- Plating
- Trivalent Zinc
Buying 50 pieces or more? Contact us for bulk pricing. Custom or modified parts: contact us.
Side 11/2" Male JIC
Side 21/2" Female NPTF 30°
Thread Type3/4-16 UNF
Tube OD1/2"
Pipe Size1/2"
MaterialSteel
Plating / FinishTrivalent Zinc
ConfigurationUnion Elbow
StandardSAE J514 / SAE J476
2504-08-08-FG is a 1/2" Male JIC x 1/2" Female NPTF 30° in the 2504-FG Series. For connecting 37° flared tubes or lines to a male pipe thread at a 45° angle.
Specifications
| Part Number | 2504-08-08-FG |
|---|---|
| Series | 2504-FG |
| Product Type | Union Elbow |
| Side 1 Connection | 1/2" Male JIC |
| Side 2 Connection | 1/2" Female NPTF 30° |
| Tube OD | 1/2" |
| Pipe Size (Side 2) | 1/2" |
| Thread Type (Side 1) | 3/4-16 UNF |
| Thread Type (Side 2) | 3/4-16 UNF |
| Material | Steel |
| Finish / Plating | Trivalent Zinc |
| Standard (Side 1) | SAE J514 - Class 2A Thread |
| Standard (Side 2) | SAE J476 |
| Weight | 0.15 lb |
| Category | JIC 37° Flare Fittings |
| Stock Status | In stock |
Connection Details
Side 1
1/2" Male JIC
- Thread3/4-16 UNF
- Tube OD1/2"
- StandardSAE J514 - Class 2A Thread
Side 2
1/2" Female NPTF 30°
- Thread3/4-16 UNF
- Pipe Size1/2"
- StandardSAE J476
Construction
- MaterialSteel
- PlatingTrivalent Zinc
- ConfigurationUnion Elbow
- Weight0.15 lb
Product Family
CategoryJIC 37° Flare Fittings
Family2504-FG
