JIC 37° Flare Fittings · 7009-F family
7009-F-08-22
1/2" Male JIC x 22 Female Komatsu · Straight
$6.90
per pieceIn stock
- Side 1
- 1/2" Male JIC
- Side 2
- 22 Female Komatsu
- Material
- Steel
- Plating
- Trivalent Zinc
Buying 50 pieces or more? Contact us for bulk pricing. Custom or modified parts: contact us.
Side 11/2" Male JIC
Side 222 Female Komatsu
Thread Type3/4-16 UNF
Tube OD1/2"
MaterialSteel
Plating / FinishTrivalent Zinc
ConfigurationStraight
StandardSAE J514
7009-F-08-22 is a 1/2" Male JIC x 22 Female Komatsu in the 7009-F Series. SAE J514 37° Flare Female Komatsu Adapter.
Specifications
| Part Number | 7009-F-08-22 |
|---|---|
| Series | 7009-F |
| Product Type | Straight |
| Side 1 Connection | 1/2" Male JIC |
| Side 2 Connection | 22 Female Komatsu |
| Tube OD | 1/2" |
| Thread Type (Side 1) | 3/4-16 UNF |
| Thread Type (Side 2) | 3/4-16 UNF |
| Material | Steel |
| Finish / Plating | Trivalent Zinc |
| Standard (Side 1) | SAE J514 |
| Weight | 0.21 lb |
| Category | JIC 37° Flare Fittings |
| Stock Status | In stock |
Connection Details
Side 1
1/2" Male JIC
- Thread3/4-16 UNF
- Tube OD1/2"
- StandardSAE J514
Side 2
22 Female Komatsu
- Thread3/4-16 UNF
- StandardSAE J514
Construction
- MaterialSteel
- PlatingTrivalent Zinc
- ConfigurationStraight
- Weight0.21 lb
Product Family
CategoryJIC 37° Flare Fittings
Family7009-F
Cross Reference
| Brand | Part Number | Higher Fitting Equivalent |
|---|---|---|
| Parker (Triple-Lok / TFD) | 6-8XHMKA6S | 7009-F-08-22 |
Cross-references are dimensional equivalents. Verify thread and pressure rating for the application. See the cross-reference resource for other brands.
