JIC 37° Flare Fittings · 2504-FG family
2504-02-02-SS
1/8" Male JIC x 1/8" Female NPTF 30° · Union Elbow
$19.04
per pieceIn stock
- Side 1
- 1/8" Male JIC
- Side 2
- 1/8" Female NPTF 30°
- Material
- Stainless Steel
- Thread
- 5/16-24 UNF
Buying 50 pieces or more? Contact us for bulk pricing. Custom or modified parts: contact us.
Side 11/8" Male JIC
Side 21/8" Female NPTF 30°
Thread Type5/16-24 UNF
Tube OD1/8"
Pipe Size1/8"
MaterialStainless Steel
ConfigurationUnion Elbow
StandardSAE J514 / SAE J476
2504-02-02-SS is a 1/8" Male JIC x 1/8" Female NPTF 30° in the 2504-FG Series. For connecting 37° flared tubes or lines to a male pipe thread at a 45° angle.
Specifications
| Part Number | 2504-02-02-SS |
|---|---|
| Series | 2504-FG |
| Product Type | Union Elbow |
| Side 1 Connection | 1/8" Male JIC |
| Side 2 Connection | 1/8" Female NPTF 30° |
| Tube OD | 1/8" |
| Pipe Size (Side 2) | 1/8" |
| Thread Type (Side 1) | 5/16-24 UNF |
| Thread Type (Side 2) | 5/16-24 UNF |
| Material | Stainless Steel |
| Standard (Side 1) | SAE J514 - Class 2A Thread |
| Standard (Side 2) | SAE J476 |
| Weight | 0.04 lb |
| Category | JIC 37° Flare Fittings |
| Stock Status | In stock |
Connection Details
Side 1
1/8" Male JIC
- Thread5/16-24 UNF
- Tube OD1/8"
- StandardSAE J514 - Class 2A Thread
Side 2
1/8" Female NPTF 30°
- Thread5/16-24 UNF
- Pipe Size1/8"
- StandardSAE J476
Construction
- MaterialStainless Steel
- ConfigurationUnion Elbow
- Weight0.04 lb
Product Family
CategoryJIC 37° Flare Fittings
Family2504-FG
